PRECISION COMPONENTS

  1. Home
  2. Precision Components

Technical Details

Size Rod Dia - M2 to M200 Dia with Lenghts up to 250M long & similar in inches


General Technical Details

Threads Type Available Metric, UNC NPT LEFT THREADS, BSW, UNF NPTF, BA, BSP BSF
Standard and Specification DIN, JIS, ISO, GB & Other Intl Standards
Types of Material Available Brass, Copper, Phosphorous Bronze, Silicon Bronze, Mild Steel & Other Copper Alloys
Material Specification
Brass
  • Brass - CuZn36Pb2 CuZn36Pb3 C 3602 DZR C 3533
  • Lead Free Brass - C 272 CZ 108 CW 508 CuZn37 C 280 CZ 109 CW 509 CuZn40
  • Naval Brass - C 464 CZ 112 CW 712 CuZn38Sn1 C 485 CuZn38Sn1 CZ 132 CW 602 CuZn36Pb2As C 3604 C 385 CZ 121 CW 614 CuZn39Pb3
  • Forging Grade - CW 612 CuZn39Pb2 High Tensile Brass
Copper Copper - C11000 Electrolytic Copper (ETP Grade) & Commercial Grade Copper
Phosphorous Bronze Pb102 /CuZn5 & Others
Silicon Bronze C65500,C65100 & Others
Mild Steel
  • Cold Heading Steel - SAE1010 SAE10120 SAE1022 SAE1018 SAE1012 SAE1541 SAE1015 SAE1008 EN3A EN19 EN2C EN15 EN15A EN32B EN2A EN2B & Others as per requirement
  • Free Cutting Steel - SAE1137 SAE1213 SAE1214 SAE1146 EN15(AM) EN1A EN1APB EN8M & Others as per requirement.
  • High Tensile Grades - 8, 8.8, 10, 10.9, 12.9
  • MS Grades - 4.6, 4.8, 5.6, 6.8
Finish
  • Electroplating - Tin / Nickle / Silver / Chromium / Gold / PVD Gold / Lead / Copper & others as required. Zinc plating - Trivalent / Yellow / White / Blue / Green & others as required
  • Oxidising - Black / Green / etc. as per requirement- Black / Green / etc. as per requirement
  • Other Processes - Heat Treatment / Stress Relieving / Chemical Blacking / Shot blasting / Powder coating etc. As per requirement
